Latest Gaming without compromise. Experience every frame without lag, with the latest AMD Ryzen 9 CPU liquid cooled with LCD panel to see your temps, Ultra Fast NVMe Samsung drive, Gigabytes latest RTX 5080 Master with LCD display (ROPS Tested) and Kingston 96GB DDR5 RAM
Product Description
AMD Ryzen 9 9950X3D 16 Core AM5 4.30GHz (5.80GHz Boost), 96GB Kingston 6000MTs DDR5 RAM, 2TB Samsung NVMe, Gigabyte RTX 5080 Master, WiFi 7 – 360mm LCD Liquid Cooler, Gaming Tower – Pre-Built System
Processor
AMD Ryzen 9 9950X3D with Radeon Graphics, 16 Core AM5 Processor, 32 Threads, 4.3Ghz up to 5.7Ghz Turbo, 144MB Cache, 170W
Processor Cores
16
Processor Threads
32
Core Clock Speed
4.30GHz
Core Boost Speed
5.70GHz
Cache
144MB
Memory
Kingston FURY Renegade KF560C32RSK2-96, 96GB (2x48GB) System Memory, DDR 5, 6000MHz, Silver, 1.35V, CL32, non-ECC Unbuffered
Memory Configuration
2 x 48GB
4 Lanes (2 occupied)
SSD Drive
Samsung 980 PRO 2TB (MZ-V8P2T0BW) NVMe SSD, M.2 Interface, PCIe Gen4, 2280, Read 7000MB/s, Write 6000MB/s
Format
NVMe M.2
Max Read/Write Speeds
Read: Up to 7000MB/S
Write: Up to 6000MB/S
Hard Drive
N/A
Optical Drive
None
Graphics
Gigabyte NVIDIA GeForce RTX 5080 AORUS MASTER 16G Graphics Card, 16GB GDDR7, 10752 CUDA Cores, 2805 MHz Core Clock, Triple Fan, RGB, 3x DisplayPorts / 1x HDMI Port
Core Clock
2805 MHz (Reference: 2617 MHz)
CUDA Cores
10752
Memory Clock
30 Gbps
Memory Size
16GB
Memory Type
GDDR7
Memory Bus
256 bit
Card Bus
PCI-E 5.0
Digital Max Resolution
7680 x 4320
Graphics Card I/O
3 x Display Ports
1 x HDMI
Operating System
Microsoft Windows 11 Home 64bit English OEI DVD Operating Software
Card Reader
N/A
Networking
LAN
5 Gigabit LAN 10/100/1000/2500/5000 Mb/s
Realtek RTL8126
Wireless LAN
802.11be 2×2 Wi-Fi 7 Module
Supports IEEE 802.11a/b/g/n/ac/ax/axe/be
Supports 2.4GHz/5GHz/6GHz* frequency band
Supports 160MHz channel bandwidth with 6GHz* frequency band
1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology
Supports Bluetooth 5.4
Supports MU-MIMO
*The Wi-Fi 7 module is supported by Microsoft Windows® 11 only. There is no driver available for Windows® 10. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.
Power Supply
Be Quiet! Dark Power 13, 850W PCIe 5.0 Fully Modular, 80PLUS Titanium, Quad Rail, 62.5A, 135mm Fan, ATX 3.0 PSU
1 x ATX-Motherboard (20+4-pin)
1 x P4+4 (CPU)
1 x P8 (CPU)
4 x PCI-e 6+2-pin (GPU)
1 x 12VHPWR cables (GPU)
12 x SATA
3 x Molex
Motherboard
ASRock X870E TAICHI AMD AM5 Socket Motherboard, E-ATX, 4x DDR5 Slots, 4x M.2 Sockets, 3x USB-C Port, Fitted I/O Shield, 5GbE LAN, Wi-Fi 7, 1x HDMI Port / 2x USB-C (USB4)
Expansion Slot
CPU:
2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes*
Chipset:
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Supports AMD CrossFire
*PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.
Supports NVMe SSD as boot disks
Storage
CPU:
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
Chipset:
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
6 x SATA3 6.0 Gb/s Connectors
* Supports NVMe SSD as boot disks
M2_1 is the first priority for M.2 installation.
M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors.
RAID
– Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
– Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
Rear I/O
2 x Antenna Ports
1 x HDMI Port
1 x Optical SPDIF Out Port
2 x USB4 Type-C Ports (40 Gb/s)*
5 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_12 are Lightning Gaming Ports.)
3 x USB 3.2 Gen1 Type-A Ports (USB32_34 supports Ultra USB Power.)
2 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x Clear CMOS Button
1 x BIOS Flashback Button
1 x Line Out Jack (Gold Audio Jack)
1 x Microphone Input Jack (Gold Audio Jack)
* Supports USB PD 3.0 up to 5V@3A (15W) charging
Internal I/O
3 x Thermistor Cable Headers
1 x Power LED and Speaker Header
1 x RGB LED Header*
3 x Addressable LED Headers**
2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***
4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
1 x Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
1 x Front Panel Audio Connector (15µ Gold Audio Connector)
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
1 x Dr. Debug with LED
1 x Power Button with LED
1 x Reset Button with LED
* Supports in total up to 12V/3A, 36W LED Strip
** Support in total up to 5V/3A, 15W LED Strip
*** CPU_FAN1 supports the fan power up to 1A (12W).
CPU_FAN2, CHA_FAN1~4, AIO_PUMP and W_PUMP support the fan power up to 3A (36W).
CPU_FAN2, CHA_FAN1~4, AIO_PUMP and W_PUMP can auto detect if 3-pin or 4-pin fan is in use.
Chassis
be quiet! Dark Base 701 Full Tower Gaming PC Case, Black, 3 pre-installed Silent Wings 4 140mm PWM high-speed fans, ARGB lighting with integrated ARGB controller
Drive Bays
5.25 bays (pcs.) –
3.5 slots (scope of delivery) 3
3.5 slots (max.) 5
2.5 slots (scope of delivery) 2
2.5 slots (max.) 3
IO Ports
USB 3.2 Gen. 2 Type C 1
USB 3.2 Type A 2
USB 2.0 –
HD Audio I/O Mic + Audio
Qi charger / Quick Charging Option
Cooling
Maximum fan installation
Maximum fans 8
Top (mm) 3x 140 / 3x 120
Front (mm) 3x 140 / 3x 120
Side (mm) –
Rear (mm) 1x 140 / 1x 120
Bottom (mm) 1x 140 / 1x 120
Dimensions
Case size excl. stands (L x W x H), (mm) 565 x 249 x 495
Case size incl. stands (L x W x H), (mm) 565 x 249 x 523
Package Weight
11.3 kg
Warranty
3 Years; 1st year parts including collect and return and a further 2 years labour warranty (UK mainland only)
