ELITE NEX WHITE W600 230V NEX LEVEL POWER
Features
Active PFC and a dual forward topology design
Excellent temperature resistance
High peak power tolerance
Durability, reliability, and safety
80 Plus standard certified efficiency
3-year warranty
ACTIVE POWER FACTOR CORRECTION AND A DUAL FORWARD TOPOLOGY DESIGN
Constructed with protective measures normally only found in high-end power supplies that improve overall safety and current stability.
EXCELLENT TEMPERATURE RESISTANCE
Capable of comfortably operating at 40°C under full loads, allowing for a longer lifespan even in warmer environments.
HIGH PEAK POWER TOLERANCE
Can reliably push an additional 100W at peak power loads for up to 20 seconds.
DURABILITY, RELIABILITY, AND SAFETY
Will perform consistently in any environment, whether you live at high altitudes or in high humidity.
80 PLUS STANDARD CERTIFIED EFFICIENCY
Maintains an efficiency of 85% at typical loads.
Specifications
Model
MPW-6001-ACBW-B
ATX Version
ATX 12V Ver. 2.41
PFC
Active PFC
Input Voltage
200-240V
Input Current
4.5A
Input Frequency
50-60Hz
Dimensions (L x W x H)
140 x 150 x 86 mm
Fan Size
120mm
Fan Bearing
Sleeve Fan
Efficiency
= 85% @ Typical Load
ErP 2014 Lot 3
Yes
Operating Temperature
0-40°C
Power Good Signal
100 – 500 ms
Hold Up Time
=10ms at 100% load
MTBF
>100,000 Hours
Protections
OVP, OPP, SCP, UVP, OTP, Inrush Protection
Regulatory
TUV, cTUVus, CE, FCC, CCC, EAC, UKCA
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
1
SATA Connectors
5
Peripheral 4 Pin Connectors
3
PCI-e 6+2 Pin Connectors
2
Series
Elite Series
80 Plus
Standard
Modular
Non Modular
Wattage
600W
