Chip Name
BX8071512700
Alder Lake
Socket
LGA1700
Total Cores
12
Number of Peformance Cores
8
Number of Efficient Cores
4
Total Threads
20
Max Turbo Frequency
4.90Ghz
Intel Turbo Boost Max Technology 3.0 Frequency
4.9Ghz
Performance-core Max Turbo Frequency
4.80Ghz
Efficient-core Max Turbo Frequency
3.60Ghz
Performance-core Base Frequency
2.1Ghz
Efficient-core Base Frequency
1.6Ghz
Cache
25MB
Total L2 Cache
12MB
Processor Base Power
65W
Maximum Turbo Power
180W
Max Memory Size (dependent on memory type)
128GB
Processor Graphics
Intel UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.50 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
32
Max Resolution (HDMI)
4096 x 2160 @ 60Hz
Max Resolution (DP)
7680 x 4320 @ 60Hz
DirectX Support
12
OpenGL Support
4.5
Intel Quick Sync Video
Yes
Intel Clear Video HD Technology
Yes
Number of Displays Supported
4
OpenCL Support
2.1
Direct Media Interface (DMI) Revision
4.0
PCI Express Revision
5.0 and 4.0
Max Number of PCI Express Lanes
20
Heatsink
Y
Packaging
Retail
Y
