Kingston’s NV2 PCIe 4.0 NVMe SSD is a substantial next-gen storage solution powered by a Gen 4×4 NVMe controller. NV2 delivers read/write speeds of up to 3,500/2,800MB/s with lower power requirements and lower heat to help optimise your system’s performance and deliver value without sacrifice. The compact single-sided M.2 2280 (22x80mm) design expands storage by up to 4TB while saving space for other components, making NV2 ideal for thinner notebooks, small-form-factor (SFF) systems and DIY motherboards.
Gen 4×4 NVMe PCIe Performance
Delivers read/write speeds of up to 3,500/2,800MB/s for an overall faster system.
Ideal for Systems with Limited Space
Easily integrate into designs with M.2 connectors. Perfect for thin laptops and small-form-factor PCs.
Extended Capacities
Available in a range of high capacities up to 4TB to meet your data storage requirements.
Features
• 4TB Storage Capacity.
• Gen 4×4 NVMe PCIe performance.
• 3-year limited warranty.
• Up to 3,500MB/s read, 2,800MB/s write.
• Cloning software not included.
Specifications
Capacity
4TB
Edition
NV2
Form Factor
M.2 (2280)
Interface
PCIe 4.0 (x4)
Host Controller Interface
NVMe
Flash Memory Type
None
Max. Read
3500 MB/s
Max. Write
2800 MB/s
DRAM Cache Memory
N/A
Latency
N/A
Max. Endurance Rating
640TB
MTBF
1,500,000 Hours
Max. Operating Vibration
2.17G (7-800 Hz)
Max. Non-operating Vibration
20G (20-1000Hz)
Connectivity
1 x M.2
Bracket
N/A
Dimensions
22 mm x 80 mm x 2.2 mm (W x H x D)
Package Type
Retail
Warranty
3 Years
