Powerful Enterprise Switch Models
The EdgeSwitch Lite simultaneously processes traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for the 24-port models and up to 70 Gbps for the 48-port models.
Enterprise-Class Features
The EdgeSwitch Lite supports an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.
Optical Fiber Backhaul
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.
Advanced UI
The comprehensive UI is easy to learn and allows administrators to configure and monitor features in a graphical user interface. For advanced users, a Command-Line Interface (CLI) is available through telnet and SSH.
Specifications
Total Non-Blocking Throughput
26 Gbps
Gigabit RJ45 Ports
24
SFP+ Ports
N/A
SFP Ports
2
Max. Power Consumption
25W
PoE
N/A
