Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support, 1.5 Gbps IPS routing, and selectable NVR storage.
Dimensions
141.8 x 127.6 x 30 mm
(5.6 x 5 x 1.2″)
UniFi Application Suite
Network
Yes
Protect
Yes
Access
Yes
Talk
Yes
Connect
Yes
Managed UniFi Devices
30+
Managed Cameras
(15) HD
(8) 2K
(5) 4K
Simultaneous Users Connected
300+
Default WAN Ports
(1) 2.5 GbE RJ45
Default LAN Ports
(4) 2.5 GbE RJ45
IDS/IPS Throughput
2.3 Gbps
Form Factor
Compact desktop
Stateful Firewall
Yes
Application-Aware Layer 7 Firewall
Yes
DPI and Traffic Identification
Yes
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
Yes
Content Filtering
Yes
Intrusion Prevention (IPS/IDS)
Yes
Ad Blocking
Yes
IDS/IPS Signatures
55,000+ with CyberSecure
License-Free SD-WAN
Yes
Site to Site VPN
Site Magic
Yes
IPsec
Yes
OpenVPN
Yes
VPN Server
Identity Endpoint One-Click VPN
Yes
Teleport Zero-Configuration VPN
Yes
WireGuard
Yes
OpenVPN
Yes
L2TP
Yes
VPN Client
OpenVPN
Yes
WireGuard
Yes
Multi-WAN Load Balancing
Yes
Dynamic Routing – OSPF
Yes
Advanced QoS
Yes
Multicast DNS (mDNS)
Yes
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
Yes
Integrated RADIUS Server
Yes
RADIUS over TLS (RadSec)
Yes
Additional Internet Failover with UniFi LTE Backup
Yes
Internet Quality and Outage Reporting
Yes
MAC Address Table Size
2000
Policy-based WAN and VPN Routing
Yes
Customizable DHCP Server
Yes
IPv6 ISP Support
Yes
IGMP Proxy
Yes
NVR Storage
Optional
Max. Power Consumption
USB type C (5V DC/5A)
Power Supply
USB type C (5V DC/5A) (Adapter included)
Supported Voltage Range
100—240V AC
System Memory
3 GB
Weight
Without SSD: 460 g (1 lb)
With SSD: 519 g (1.1 lb)
Enclosure Material
Polycarbonate
LCM Display
0.96″ status display
Management
Ethernet
Bluetooth
LEDs
Ethernet
Certifications
CE, FCC, IC
